European Welding Rotator With PU Wheels , 40T Capacity Greece Market Pipe Welding Roller Stands
Self aligning Pipe Welding Rollers
1. Self aligning pipe welding rollers will adjust the tank diameters automatically.
2. Foot pedal for spot welding will be more convenient.
3. CE certificates supported for European market.
4. Low noise transmission and stable turning roller during working.
5. 220V~600V 1/3 Phase 50/60Hz all ok.
6. If one set will be package in wooden case.
7. Original: Wuxi Success Machinery Equipment Co., Ltd - Jason Qian
8. Supply the European standard work manual.
Pipe Welding Rollers Specification
| Model | HGZ-5 | HGZ-10 | HGZ-20 | HGZ-30 | HGZ-40 |
| Max Capacity | 5 T | 10 T | 20 T | 30 T | 40 T |
| Roller Diameter (mm) | 250 | 300 | 350 | 350 | 400 |
| Roller Width (mm) | 100 | 120 |
| Working Range (mm) | 250-2300 | 320-2800 | 500-3500 | 530-3700 | 600-4200 |
| Roller Speed (m/h) | 6-60 |
| Motor Power (kw) | 0.75 | 1.1 | 1.5 | 2.2 | 3 |
| Option : | □ Moving wheels □ Wireless Control □ Remote Control |
Note: Made by Wuxi Success Machinery Equipments Co., Ltd / Self Aligning Welding Rotator
Pipe Welding Rollers Applications
2. SAW / TIG welding are all supported.
3. Tanks / Pipes welding
4. Pressure vessles
5. Heat exchanger etc.
Details Control system and Brand On Pipe Welding Rollers
1. Inverter is from Danfoss Brand
2. Motor is from CE Invertek Brand
3. Reducer is from Cable. Made in China.
4. Electric system is from Schneider
5. All spare parts with CE certificates supported as well.
Attention please
1. All our pipe welding rotators have 20% over weight design, but we suggest used on the safe rangs.
2. We have strong delivery team, including the Sea freight and Air transportation.
3. Just advise me your desitination port then we will give you the final CIF price.
