Product Description:
1.Our pipe welding rotators pack One drive piece roller & one idler piece roller together as one set for sale.
2.Our tank tuning rolls' drive rotation speed is in digital readout.
3.Top-class electronic components from Schneider to ensure long time using life
4.Remote hand control, Radio hand control & Foot pedal control are all avaialble.
5.100% new from original manufacturer
6. If your single pipe length more than 8 meter, we suggest you choose one drive roller and two idler rollers to support.
Features:
1. Special design welding turning roller will support under the pipe.
2. Welding guns on the arm for automatic welding.
3. Seam tracker available for adjust the seam welding.
Technical Parameters:
| Model | PT-30 |
| Load capacity-Set | 3 ton maximum |
| Rotation capacity | 3 ton maximum |
| Vessels diameter | Min.150mm ~ Max.900mm |
| Rotation speed | 100~1000 mm/min VFD |
| Rotation power | 2*0.37 kw |
| Roller wheels | PU |
| Control way | Remote hand control 8m cable |
| Foot pedal control | Foot pedal switch 6m cable |
| Voltage | 380V~480V 50/60Hz 3Phase |
| Color | Customized |
| Warranty | 1 Year |
Applications:
1. Pressure vessel;
2. Pipe manufacturing industries
3. Wind power fabrication
4. Chemical & fuel storage tank fabrication
Support and Services: 1. We provide 12month guaranty period for the whole machine quality.
2. During this time, any issue proved because of the machine flaw itself,we would take the whole responsibility of it.
3. Except of the guaranty period,technical advisory support is available freely covering the whole using life of the machine.
4. Engineer service on user premises is also available for necessary.
Packing and Shipping:
1. Seaway is the most common transportation way for oversea trading.
2. Depends on your location, combined transport by rail and sea is also an option.
3. Certainly railway transportation is also acceptable if it is the most suitable approach.
4.All package in wooden case for delivery to avoid damage.
5.It will be placed in an anti-rust coating for extra protection and then covered with a thick foam sheet.
6.The crate will be sealed with screws and nails to ensure that it is secure and will not be damaged in transit.
7.Once it is shipped, it will be tracked with a tracking code to ensure that it is delivered safely and on time.
8. All boxes are labeled with the product name and number, and the shipper's contact information.
FAQ:
- Q: What is the brand name for the Pipe Welding Rotator?
A: The brand name for the Pipe Welding Rotator is Weldsuccess.
- Q: Where is the Pipe Welding Rotator manufactured?
A: The Pipe Welding Rotator is manufactured in China.
- Q: What certifications does the Pipe Welding Rotator have?
A: The Pipe Welding Rotator has ISO/CE/CO certification.
- Q: What is the minimum order quantity for the Pipe Welding Rotator?
A: The minimum order quantity for the Pipe Welding Rotator is 1 set.
- Q: How is the Pipe Welding Rotator packaged?
A: The Pipe Welding Rotator is packaged in a wooden case.
